8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper

  • 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper
  • 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper
  • 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper
  • 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper
  • 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper
  • 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper
Place of Origin Guangdong, China
Merknaam MYSUN
Certificering UL Certification
Model Number E239689
Minimum Order Quantity 3050
Prijs $0.01-0.02

Contacteer me voor vrije steekproeven en coupons.

Whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

Als u om het even welke zorg hebt, verstrekken wij de online-Help van 24 uur.

x
Productdetails
Temperature rating 200C Conductor material Tinned Copper wire
Insulation material Silicone Rubber Rated voltage 600v
Conductor type tinned copper AWG size 8
Conductor construction 1650/0.08 Conductor diameter 4.00±0.30mm
Insulation thickness 1.15mm Overall diameter 6.30±0.3mm
Jacket material Silicone rubber Wire type insulated
Standard compliance UL 758 Color options Optional
Conductor core Copper
Markeren

8AWG silicone rubber wire

,

UL3512 tinned copper wire

,

200C silicone insulated wire
Laat een bericht achter
Productomschrijving
Soft Silicone Wire 1650/0.08 8AWG UL3512 High Temperature Kabel Silikon for Lithium Battery
Product Specifications
Attribute Value
Temperature 200°C
Type Insulated
Application Home appliance, lighting, heater, motor & generator
Conductor Material Tinned Copper wire
Rated voltage 600V
Insulation Material Silicone Rubber
Standard UL 758
Color Optional
Product Description
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China.
8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper 0 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper 1
Technical Specifications
Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm)
26 25/0.08 0.48 0.78 2.10±0.1
24 41/0.08 0.60 0.78 2.20±0.1
22 65/0.08 0.78 0.78 2.50±0.1
20 104/0.08 0.95 0.78 2.55±0.1
18 164/0.08 1.17 0.78 2.80±0.1
16 261/0.08 1.47 0.78 3.10±0.1
14 415/0.08 2.10 0.78 3.70±0.1
12 660/0.08 2.70 0.78 4.30±0.1
10 1050/0.08 3.40±0.30 1.15 5.50±0.2
8 1650/0.08 4.00±0.30 1.15 6.30±0.3
Contact Us to Get the Most Cost-effective Quote
8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper 2 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper 3 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper 4 8AWG UL3512 Silicone Rubber Wire 200C Tinned Copper 5
Frequently Asked Questions
  • Who Are We? Professional manufacturer of high-temperature wires and cables with 26 years of experience, headquartered in Shenzhen with production bases in Dongguan and Jingzhou.
  • What Can We Provide? High-temperature wires and cables, silicone tubing including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
  • Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
  • Certifications: UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
  • Services: Multiple delivery terms (FOB, CIF, EXW, etc.) and payment options (T/T, L/C, PayPal, etc.).
