2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable

  • 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable
  • 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable
  • 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable
  • 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable
  • 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable
  • 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable
Place of Origin Guangdong, China
Merknaam MYSUN
Certificering UL Certification
Model Number E239689
Minimum Order Quantity 2000
Prijs $1-3

Contacteer me voor vrije steekproeven en coupons.

Whatsapp:0086 18588475571

wechat: 0086 18588475571

Skype: sales10@aixton.com

Als u om het even welke zorg hebt, verstrekken wij de online-Help van 24 uur.

x
Productdetails
Temperature rating 200C Shape ROUND
Diameter 2 AWG Conductor material Tinned Copper wire
Conductor type tinned copper Insulation material Silicone Rubber
Rated voltage 600v Conductor construction 6692/0.08
Conductor diameter 8.70±0.5mm Insulation thickness 1.52mm
Overall diameter 11.8±0.5mm Wire gauge 2 AWG
Material Copper Jacket material Silicone rubber
Color options Optional
Markeren

2 AWG silicone wire

,

UL3512 high temp cable

,

flexible silicone insulated wire
Laat een bericht achter
Productomschrijving
UL3512 2AWG Super Soft Silicone Wire 6692/0.08 Flexible High Temperature Hybrid Lithium Battery Cable
Product Specifications
Attribute Value
Temperature 200°C
Shape ROUND
Diameter 2 AWG
Type Insulated
Application Home appliance, lighting, heater, motor & generator
Conductor Material Tinned Copper wire
Insulation Material Silicone Rubber
Rated voltage 600V
Standard UL 758
Color Optional
Product Description
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China.
2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable 0 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable 1
Technical Specifications
Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm)
26 25/0.08 0.48 0.78 2.10±0.1
24 41/0.08 0.60 0.78 2.20±0.1
22 65/0.08 0.78 0.78 2.50±0.1
20 104/0.08 0.95 0.78 2.55±0.1
18 164/0.08 1.17 0.78 2.80±0.1
16 261/0.08 1.47 0.78 3.10±0.1
14 415/0.08 2.10 0.78 3.70±0.1
12 660/0.08 2.70 0.78 4.30±0.1
10 1050/0.08 3.40±0.30 1.15 5.50±0.2
2 6692/0.08 8.70±0.5 1.52 11.8±0.5
Contact Us to Get the Most Cost-effective Quote
2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable 2 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable 3 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable 4 2 AWG UL3512 Silicone Wire 200C High Temp Flexible Cable 5
Frequently Asked Questions
  • Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, with production bases in Dongguan and Jingzhou.
  • What Can We Provide? High-temperature wires and cables, silicone tubing including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
  • Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
  • What Certifications Do We Have? UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
  • What Services Can We Provide? Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment methods: T/T, L/C, PayPal, Western Union, Cash.
